Guardrail Offset Block
Part of the Guardrail Spacer range · Highway Guardrail.
Model: Offset block
The guardrail offset block holds the rail away from the post at the designed offset, which is what lets a W-beam barrier deflect and redirect instead of snagging. Guardrail Spacer are considered as passive protectors with a view to ensure the safety of the pedestrians by the wayside and the vehicles. Highway guardrails are designed in pursuance to the principle of keeping the vehicle inside the road in a secure way and…
- Standard ASTM,AISI,DIN,GB
- Material Q235, Q345,other standard steel, etc
- Surface Hot dip galvanized, powder coated
- Thickness 2.5mm – 5mm or as request
- MOQ 1 × 20GP container
- Lead time 15–25 days
- Mill test certificate with every shipment
- Shop drawings and setting-out plan included
- Custom lengths, hole patterns and coating weights
Technical specification
| Product Name | Galvanized Guard rail Used Spacer |
| Material | Q235, Q345,other standard steel, etc |
| Technology | cold rolled |
| Surface Treatment | Hot dip galvanized, powder coated |
| Specification | U, C, H, F,Sigma,Box,Trapezoidal Spacer,Offset Block |
| Thickness | 2.5mm – 5mm or as request |
| Zinc Coating | 350g-600g/m2 |
| Country of Origin | Shandong, China |
| Standard | ASTM,AISI,DIN,GB |
| Certificate | ISO9001:2008 ,GB/T19001-2008,CE,SGS |
| Other special specification as per client’s requirement or drawings | |
Dimensions shown are the standard range. Non-standard lengths, hole patterns and coating weights are produced to order — send your drawing for a confirmation drawing.
Description
Offset block: where it is used
The offset block is the general-purpose block-out that holds a guardrail beam away from the post. It is the part that sets how far the rail stands off the post face, and that distance is what lets the beam deflect and absorb impact energy. Offset blocks are used across W-beam, thrie-beam and box-beam systems, on both driven and bolted posts.


How an offset block absorbs energy
An offset block is the spacer between the rail and the post, and its main job is to keep the two apart so the beam can bend in a crash instead of being crushed against the post. The thicker the block, the further the rail can deflect before it reaches the post, so the thickness is chosen with the containment level of the barrier in mind. We press the block from Q235 or Q345 steel and hot-dip galvanize it.
Choosing the right offset
The offset has to match the post section and the beam. Too little offset and the rail bears on the post and loses its deflection; too much and the bolt set becomes the weak point. Tell us the post and the beam you are running and we will confirm the block thickness, then drill the block to your bolt pattern so it fits without reaming.
Standards, sizes and ordering
Offset blocks are supplied to AASHTO M180, AS/NZS 3845, BS EN 1317 and JT/T 281, or to your own drawing. Send the post section, the beam profile and the bolt spacing and we quote from our own mill. Samples can be sent if you want to check the thickness and the coating before you order.
Frequently asked questions
- What does an offset block actually do?
- It sets how far the rail stands off the post face, and that distance is what lets the beam deflect and absorb impact energy. Offset blocks are used across W-beam, thrie-beam and box-beam systems, on both driven and bolted posts.
- How do we choose the right offset?
- The offset is set by the system detail rather than by preference, because it is the distance the barrier was designed and tested at. Send the drawing or the standard your project follows and we will match the block depth to it rather than leave the site to set an arbitrary stand-off.
- What are the blocks made of?
- Cold-rolled steel strip in Q235 or Q345, from 2.5 to 5 mm, hot-dip galvanized or powder coated with a 350 to 600 g/m² zinc coating. U, C, H, F, sigma, box and trapezoidal sections are all produced on the same line.
- We call this part a blockout. Is it the same thing?
- Yes. Offset block, block-out and spacer are three names for the same component, and which one a project uses varies with the standard it follows. What matters when ordering is the section it matches, the block depth and the bolt pattern.
Key features
- Box, H, U, C, F and trapezoidal sections plus offset blocks
- Holds the beam at the offset it was crash-tested at
- Hot-dip galvanized to AASHTO M180 with the matching beam
- Punched to the same bolt pattern as the beam it pairs with
- Supplied loose or pre-assembled with bolts and washers
Where it is used
- Beam-and-post barrier runs
- Bridge decks and narrow offsets
- Median and shoulder installations
- Alignment offsets at transitions
- Guardrail repair and replacement
- Curved and sloped sections
Complete the system
A barrier is supplied as a set. These are the components that go with this item on a typical installation.
Not sure which specification fits?
Tell us the road class, design speed and the standard your client is working to. Our engineer will come back with the section, the coating weight and the post spacing that meet it — and the price for the quantity you need.
